LC Upc mm Quadruple Type Fiber Optic Network Adapter

Overview
Certifications
Packaging & Shipping
Company Profile

Overview

Basic Info.

Model NO.	LC quadruple
Number of Cores	Multi-Core
Ferrule Endface	PC(UPC)
Shape	Rectangular
Application	Network Equipment
Light Source TYPE	Sc
Connector Type	Sc
Brand	OEM
Inner Sleeve	Ceramic
Colour	Blue/Grey/Green
Delivery Time	3-5 Days
Transport Package	PE Bag+ Carton
Trademark	OEM
Origin	China
HS Code	8536700000

Product Description

Fiber optic adapter is also called fiber optic coupler. It contains the interconnect sleeve, that holds the two ferrules together. It is used to provide a cable to cable fiber connection.

Characteristics:
Telcordia, ANSI,TIA/EIA standard compliance High precision alignment Good durability and exchangeability Various Connector Type Available High temperature stability Low Insertion Loss and return loss

LC Upc mm Quadruple Type Fiber Optic Network Adapter

Application:
Optical Fiber Communications,Video,LAN, CATV Systems Optical Network Equipments,optical Test Equipments Module Pigtails,Multi media,Premise Active device termination installations

LC Upc mm Quadruple Type Fiber Optic Network Adapter

Connector Type	LC,FC,SC,MU,ST,MTRJ,Hybrid
Fiber Type	Single-mode	Multi-mode
Insertion Loss	≤0.2dB
Return Loss	PC≥45dB; UPC≥50dB; APC≥60dB	≥30dB
Durability	≤0.2dB,after 1000times
Operation Temperature	-40ºC~+75ºC
Storage Temperature	-40ºC~+85ºC
