4 Core Flat Self Supporting FTTH Outdoor Drop Fiber Optic Cable Gyfxtby
Description
- Overview
- Product Description
- Product application
- Performance characteristics
- Detailed Photos
- Product Parameters
- Company Profile
- Our Advantages
- FAQ
Basic Info.
| Model NO. | GYFXTBY |
| Connection Structure | SC |
| Material Shape | Flat Wire |
| Allowed Lateral Pressure | 100(N/100mm)<1000(N/100mm) |
| Allowed Tensile Strength | 100N<1000N |
| Core | 1-12 |
| Certification | RoHS, CE, ISO9001 |
| Brand | OEM |
| Sheath Material | LSZH/Pvs |
| Color | Black or White |
| Diameter | 3.0*5.0mm |
| Strength Member | Steel Wire/ FRP/ Kfrp |
| Length | 4km/Roll |
| Package Customize | Yes |
| Fiber Brand | Yofc/ Fiberhome/ Coring |
| Transport Package | Wooden+Box |
| Specification | 390*380*390mm |
| Trademark | HAOKAI |
| Origin | Dongguan |
| HS Code | 85447000 |
| Production Capacity | 1000000m/Day |
Product Description
4 Core FRP Flat Self Supporting FTTH outdoor Drop fiber optic Cable GYFXTY GYFXTBY
GJXH optical fiber unit is positioned in the center. Two parallel Fiber Reinforced(FRP) are placed at the two sides. A steel wire as the additional strength member is also applied. Then, the cable is completed with a black or color LSZH sheath.
• Patch cord
• Tail cable
• Indoor pigtail | wiring | pigtail cable
1.Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property.2.Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber.3.Single steel wire as the additional strength member ensure good performance of tensile strength.4.Simple structure, light weight and high practicability.
5.Novel flute design. easily strip and splice, simplify the installation and maintenance.
6.Low smoke, zero halogen and flame retardant sheath.
| Fiber Model | Fiber Count | Cable Size(mm) | steels specifications mm | Weight kg/km | Tensile resistance Long/short term N | Crush resistance Long/short term N/100mm |
| GJXH | 1-4 | 3.0*2.0 | 2*0.45 | 10 | 40/80 | 500/1000 |
| GJXCH | 1-4 | 5.0*2.0 | 1.0+2*0.45 | 20 | 300/600 | 1000/2200 |
